14:00 - 15:40
Room: T1 C
Chair/s:
Jon Martinez-Rico (Tekniker)
HYB25-13
A Hybrid Hydro-ESS Simulation Model to Meet FCR-D Requirements
01 HYB26-13
Presented by: Joel Gerdes
Joel Gerdes 1, Christian Ekstrand 1, Peiyuan Chen 2, Victor Lidskog 1, Eddie Eriksson 1
1 Solvina AB, Sweden
2 Departement of Electrical Engineering, Chalmers University of Technology, Sweden
In 2023, the technical requirements for frequency containment reserve - disturbance (FCR-D) in the Nordic synchronous area were revised, introducing stricter demands on dynamic response and new stability criteria. Hydropower plants (HPPs) constitute the largest share of FCR-D provision in the Nordic region. However, HPPs exhibit inherent dynamic delays, which may prevent some units from complying with the revised requirements. A hybrid solution with a fast-acting energy storage system (ESS) is therefore proposed to assist the HPP, enabling the hybrid plant to fulfil the requirements for FCR-D. This paper models a Kaplan HPP in Sweden which fails to meet the revised FCR requirements on its own. A dynamic parallel power sharing strategy between the HPP and ESS for primary frequency control within a hybrid power plant is proposed. Both battery energy storage system and supercapacitor energy storage system are considered for the hybrid plant, and the most cost-effective configuration is explored.
